Monitoring your internet connections with OpenWRT and a Telegram Bot

For the past 5 years or so, I have been using a single ISP at home and mobile data for backup when it went down. But since last few months, the ISP service became a bit unreliable – this is more related to the rainy season. Mobile data doesn’t give fiber like constant speeds I get on the wire. It’s very annoying to browse at < 10 Mbps on mobile data when you are used to 100 Mbps on the wire.

I decided to get another fiber pipe from a local ISP. One needs to be very unlucky to have both going down at the same time – I hope that never happens. Now the question is how to monitor the two connections: Why do I need monitoring? – so that I can inform the ISP when it goes down, with the fail-over happening automatically thanks to OpenWRT’s mwan3 package, I won’t ever know when I am using which ISP (unless I am checking the public IP address, of course).

Continue reading “Monitoring your internet connections with OpenWRT and a Telegram Bot”

Advertisements

Asterisk PBX with Reliance PRI Line using Digium TE131F

So I got an opportunity to set up Asterisk PBX with a Reliance Communications E1 line. I have worked with Asterisk PBX, but without PSTN interfacing. This post is about what all stuff I have done to get a Reliance E1 line with Digium TE131F card.

Having explored a lot of other distributions like Fedora, Arch, Gentoo, Sabayon, etc. since I ventured into Linux world and learning the internals of Linux and how different components are stitched together I settled on Ubuntu. It’s my favorite these days because  everything seems to work out of the box… except when it doesn’t, then you have PPAs. 😛 For this project I have installed Ubuntu 16.04 server edition.

Continue reading “Asterisk PBX with Reliance PRI Line using Digium TE131F”

ZFS convert stripe to striped-mirror

OpenZFS LogoI’m a huge fan of ZFS because of its performance and other features like snapshots, transparent compression. In fact I had switched to FreeBSD for servers just because it had native ZFS support. But as of Ubuntu 16.04, ZFS is officially supported for non-root partitions.

Now I’m migrating a FreeBSD server to Ubuntu 16.04 with ZFS for data storage – this is happening because I need support for some special hardware which has drivers only for Linux and I do not have a spare server machine of same capacity in terms of memory/disk/processor.

My case –
Here’s the zpool layout on my existing FreeBSD server:

Each of those disks are 1TB in size and the layout here is something known as RAID 10, or striped mirroring. Striped mirroring can be extended to more than four disks but in my case, I have two pairs of disks. Each pair is mirrored and the each such mirror is striped, illustrated as in the image below:

Image taken from techtarget.com, their trademark/copyright holds.

The advantage of this layout is that you get read speed of four disks, and write speed of two disks and a failure tolerance of two disks (but in different mirrors) at the same time.

I have a spare 1TB disk which I can use for preparing a new server using a low-end machine for migration. I remove one of the disks from the live server so the pool there runs in a degraded state. The removed disk is used in the new server. So I create this zpool in Ubuntu:

The pool created here is a plain simple stripe. To convert this into a striped-mirror, the zpool attach command has to be used:

With this, the pool now becomes a striped mirror:

Perfect! 😀



Group based HTTP basic authentication using Nginx and MySQL with help of Lua

Recently I moved from Apache to Nginx on one of my servers due to increase in traffic. But I was using HTTP Basic authentication with group based authorization on Apache in this manner:

However, there’s no AuthGroupFile  in nginx. But LUA, a programming language is supported in nginx. So here’s how I used LUA and MySQL for achieving this:

Now the real magic comes in the authenticate.lua  script, I’m posting the code below which is available in Github as well:

The group authentication script looks for users and groups in a table called http_users. Since this is a script you can modify the way users are searched for in the database or change the database altogether!
The lua modules required to run this script are: resty.mysql, resty.session, resty.string and cjson. Though the passwords are stored in the database as a SHA224 hash, the comparison of the password is done by the database itself. I did not convert the password to hash before sending it to database, so you may want to review this in case you are using remote database. I’m using local database over Unix socket so it doesn’t matter much.

The table and triggers I have for the same:

The triggers are required to convert the INSERT  or UPDATE statements into SHA224. I’m using MySQL’s SET data type to ensure that the group value is fixed. The same values can be used by Nginx in $user_group  variable before specifying the access_by_lua_file  directive.

CloudFlare Dynamic DNS using OpenWRT

I use dynamic DNS for my home internet connection so that I can access the machines from anywhere on the internet. And I use OpenWRT on my router. Earlier I was using Namecheap for managing DNS but I switched to CloudFlare for performance and security reasons of the website.

Unfortunately CloudFlare doesn’t support updating IP via shell script — well, it sort of does but the JSON stuff gets very messy with quoting in shell scripts, so I wrote a Lua script to update my IP whenever my PPPoE connection starts up; I have dropped the script in /etc/ppp/ip-up.d  so it gets executed by pppd whenever my connection comes up. You can run this script via cron or put it /etc/hotplug  if you wish to. This script uses LuaSocket, LuaSec, JSON4Lua and libubus-lua libraries that are easily installable on an OpenWRT router with 4 MB flash memory.

Now I can have the benefits of CloudFlare without losing out on DDNS :D. Here’s the code:

Suggestions? Post in comments or fork on GitHub.

Remote desktop server XRDP on Linux Mint, Ubuntu

If you’d like to access your Linux desktop over the network from anywhere in the world, or just want to share your computer’s resources on the LAN by giving all users accounts on your computer, you can set up a remote desktop server. It is quite easy to do so, and the best part is that it is compatible with the remote desktop client on Windows too, thanks to the software called XRDP which talks Remote Desktop Protocol (RDP).

Are you surprised that a blog that usually used to talk about Gentoo, is now posting about Ubuntu? Well, I made switch on my personal machine to Linux Mint Cinnamon because I was bored with Gentoo. I have nothing against Gentoo, and I still love it. It’s the perfect distribution if you want to customize your OS to the core.

If you are going with Linux Mint, I’d highly recommend the MATE desktop. MATE is basically a fork of the original GNOME 2 project. GNOME 3 / Cinnamon / Unity won’t work with XRDP because they rely on 3D graphics which is not possible (yet) on X11RDP or Xvnc (correct me if I’m wrong). You could also go with the other desktop environments like XFCE or LXDE if you prefer. Even KDE works fine in the remote desktop environment because it does not solely rely on 3D graphics.

Continue reading “Remote desktop server XRDP on Linux Mint, Ubuntu”

FreeBSD IPFW NAT and Jails

IPFW in FreeBSD has built-in support for NATing and the configuration syntax is same as that of natd. It took me quite some time to figure out how to NAT for jails while ensuring that certain jails can have public IPs.

Configure the nat on one of the IP addresses:

When using stateful firewall, the NAT rule for incoming traffic must appear before check-state:

Other rules (service ports) can be placed below this:

Then the NAT rule for outgoing traffic:

Notice above, I am NATing only traffic that comes from 10.0.0.0/8 . I allocate jails an IP on that subnet (unless I need a public IP for the jail). If the source is not mentioned in the rule, it will NAT even public IPs!

And finally, the outgoing ports:

The catch here is that we jump to the NAT rule only if the traffic comes from 10.0.0.0/8 . If the traffic is coming from somewhere else (for example, a public IP allocated to one of the jails), it will hit the second rule and directly allow it.

Make sure you have the rule to allow loX traffic if you have separate clone interfaces for each jail.

Final touches:

The firewall script ipfw.rules must to contain other rules for services, icmp, etc not mentioned here.
Everything working smoothly now – ip4 from private jails, ip4 and ip6 from others 😀

FreeBSD ipfw: add_dyn_rule: Cannot allocate rule

One of the servers I run has FreeBSD 10. It hosts a high traffic Magento site. Magento being a very heavy application, requires a dedicated server. The site’s performance is very bad when it is hosted on VPS — or perhaps that depends on provider / needs tuning. Not my site. My task was to move it to dedicated server so I don’t have to consider all that stuff.

As someone new to FreeBSD, I try to stick to tools and utilities that are provided by FreeBSD itself and do not rely on those provided by other BSDs. This rule is quite flexible, but I can’t cite examples of relying on tools by other BSDs that I’m using right now. So, naturally, for firewall I chose IPFW which is FreeBSD’s own firewall. The other firewalls supported by FreeBSD are PF (which comes from OpenBSD) and IPFilter (which comes from NetBSD).

Continue reading “FreeBSD ipfw: add_dyn_rule: Cannot allocate rule”

A failed experiment with GlusterFS

GlusterFS is a clustered file system that can be used when you want to share the content across different machines which can be accomplished by NFS as well. But the difference is, NFS failover is hard.

In GlusterFS, you can add two servers known as bricks in Gluster’s terminology on which your volume can be created as a replica. All data is replicated to both the servers by Gluster. GlusterFS has support for advertising the volumes as NFS shares as well, but I didn’t use it because of the basic reason – failover.

Continue reading “A failed experiment with GlusterFS”
